1050 Aluminum Coil

1050 aluminum coil specification

Product name: 1050 aluminum coils

1. TensileStrength(Mpa): 60-100

2. EL(%): ≥23

3. Density(g/cm³): 2.68

Heat treatment specification for 1050

1) Complete annealing: 390-430 ℃; With the different effective thickness of the material, the holding time is 30-120 min; At the speed of 30-50 ℃ / h, it is cooled to 300 ℃ with the furnace, and then air cooled.

2) Rapid annealing: 350-370 ℃; With the different effective thickness of the material, the holding time is 30-120 min; Air or water cooled.

3) Quenching and aging: quenching 500 ~ 510 ℃, air cooling; Artificial aging 95 ~ 105 ℃, 3 h, air cooling; Natural aging 120h at room temperature.

1050 aluminum coil description

1050 aluminum coils are one of the pure aluminum coil series product with the aluminum content 99.5%. It has small density, good plasticity, high corrosion resistance, electrical conductivity and thermal conductivity.

1050 aluminum sheet rolls are widely used in daily necessities, constructions, kitchenware, decorations, lighting appliances, reflectors, heat sinks, road signs, electronics, lamps, nameplates, electrical appliances, stamping parts and other products etc, requirements are not high.

The chemical composition of 1050 aluminum coils
