5 Bar Aluminum Tread Plate

5 Bar Aluminum Tread Plate Introduction

Defined by its style, 5 bar pattern aluminum tread plate has five parallel diamond-shaped strips, instead of the regular tread plate, which is a single strip alternating in an offset pattern.

Common applications of 5 bar aluminum tread plate  include ramps, toolboxes, decorative floors or walls, vehicle treads or kickboards, trailers, dock surfaces and stairs.

According to the shapes, 5 bar tread plate aluminum plate can be divided into large five bars and small five bars aluminum tread plate.

5 bar aluminum Tread Plate nicknames

Also known as aluminum checker plate, chequer plate, aluminum diamond plate, aluminum checker plate cover. Aluminium floor access cover.

Quality standard of 5 bar aluminum tread plate

The five-bar pattern aluminum plate has many advantages such as beautiful appearance, anti-skid and so on.

Users should pay attention to their quality when buying patterned aluminum sheets: the quality of five-bar patterned aluminum sheets is not only reflected in the basic mechanical properties and mechanical properties, but also in the pattern pattern rate, pattern height and pattern height difference.

5 Bar Aluminum Tread Plate Specifications

Our factory provides customized services of 5 bar tread plate aluminum plate, including thickness, size, alloy, etc.

Production specifications requested by customers we are working with

.063, .100 and .125 are three common thickness gauges

5052-H32 Diamond Plate 0.125"

5052-H32 5-Bar Plate 0.125"

5052-H32 Diamond Plate 0.188"

5052-H32 5-Bar Plate 0.188"

5052-H32 5-Bar Plate 0.250"

Aluminum 5-Bar Plate - .063" X 12" x 12"

Aluminum 5-Bar Pedals - .063" X 12" x 24"

Aluminum 5-Bar Pedals - .063" X 12" x 48"

Aluminum 5-Bar Treadplate - .063" x 24" x 24"

Aluminum 5-Bar Treadplate - .063" x 24" x 48"

Aluminum 5-Bar Treadplate - .063" x 24" x 72"

Aluminum 5-Bar Treadplate - .063" x 36" x 48"

What's the usage of 5 Bar Aluminum Tread Plate?

The main purpose of patterned aluminum is anti-skid and decoration. It is often used in special places such as cold storage, ships, carriages, and stairs. In addition, aluminum checkered plates are widely used in furniture, such as refrigerators, air conditioners, carriages, platforms, packaging pipes, screen frames, and various suspensions. Beams, table legs, decorative strips, handles, wire grooves and covers, chair tubes, etc.
